Ürün Kodu: RS-ES-500-54XQS
| ÜRÜN ADI | Anahtarlama Cihazı (Switch) |
| ORJİNAL ÜRÜN KODU (P/N)* | RS-ES-500-54XQS |
| ÜRÜNÜN MARKASI* | rubisec |
| ÜRÜNÜN MODELİ* | RS-ES-500-54XQS |
| Anahtarlama Cihazı (Switch) | |
| Bağlantı Noktası Sayısı: | 54 |
| Sabit Bağlantı Noktaları Açıklaması: | 24 adet 1G/10G SFP+ fiber port yuvası , 4 adet 40G/100G QSFP28 fiber port yuvası 1 adet 10/100/1000Base-T bakır yönetim portu |
| Anahtar Bant Genişliği: | 1920 Gbps |
| Yığınlama: | Yığınlama desteği vardır |
| Yönetim Yazılımı: | WEB GUI, CLI Konsol, SNMP, SSH, SSL |
| Paket İletim Hızı (Mpps): | 1607 Mpps |
| Güvenlik 1: | Port security, IP+MAC+port binding, DHCP Snooping, DHCP Option 82, Port isolation, command line hierarchical protection, uRPF, IEEE 802.1x certified, Radius, BDTacacs+ certified, Suppression of multicast, broadcast, and unknown unicast packets Prevent DDoS attacks, TCP SYN Flood attacks, UDP Flood attacks, etc. ACL flow identification and filtering security mechanism based on L2/L3/L4 |
| Güvenlik 2: | ZTP(Zero Touch Provisioning), Management based on browser Web, Traffic statistics analysis such as sFLOW, Support USB for file upload and download, NTP, Syslog, ISSU, 802.1AG and 802.3AH, Power alarm function, Console, Telnet, SSH 2.0, Ping, Tracert, Track, Telnet remote maintenance, SNMP (Simple Network Management Protocol), File upload and download management in TFTP mode, Fan, temperature alarm, debugging information output, Classified alarm, SNMP v1/v2/v3, RMON event history |
| Fiziksel Özellikler: | Calısma sıcaklıgı -20°C / +55°C aralıgına sahip IP30 19-inch Rack Montaj, 32K MAC Adresi, 442.5*315*44mm, <9,8 kg |
| Diğer Özellikler 1: | Virtualization, Local stacking and remote stacking, MAD stack split detection mechanism based on LACP, BFD, and ARP, Distributed device management, distributed link aggregation, and distributed elastic routing, Ipv4 Policy routing, BFD for OSPF, BGP, Equal-cost routing to achieve load balancing, Static routing, RIP v1/v2, OSPF, BGP, IS-IS, BEIGRP |
| Diğer Özellikler 2: | MLD v1/v2, MLD Snooping, ICMPv6, DHCPv6, ACLv6, IPv6 Telnet, Manual tunnel, ISATAP tunnel, 6to4 tunnel, IPv6 static routing, RIPng, OSPFv3, BGP4+, IPv6 neighbor discovery, Path MTU discovery, MAC Exchange View and clear the MAC address, MAC address aging time is configurable, |
| Diğer Özellikler 3: | IEEE 802.1AE MacSec Security Control, Limit the number of MAC address learning, Black hole MAC table entry, MAC address filtering function, Static configuration and dynamic learning of MAC addresses, VLAN 1:1 and N:1 VLAN Mapping, Basic QinQ and flexible QinQ functions, 4K VLAN entries, GVRP, Private VLAN |
| Diğer Özellikler 4: | 10G port aggregation, Static aggregation, Dynamic aggregation, Flow Monitoring sFLOW, DHCP DHCP Snooping option82/ DHCP Relay option82, DHCP Client, DHCP Snooping, DHCP Relay, DHCP Server, Zero configuration methods such as DHCP auto-config and CWMP-TR069, STP/ERPS BPDU protection, root protection, loop protection, |
| Diğer Özellikler 5: | ERPS Ethernet Protection Protocol (G.8032)802.1D (STP), 802.1W (RSTP), 802.1S (MSTP),Multicast Enhanced L3 multicast protocol, Multicast traffic replicated across VLAN, MFF, MVRP, PIM snooping, PIM-SM, PIM-DM, Multicast group policy and multicast group number limit, IGMP v1/v2/v3, IGMP Snooping v2/v3, IGMP Fast Leave |
| Diğer Özellikler 6: | Free ARP, Dynamic ARP Inspection, ARP source suppression, ARP anti-attack, Static entries, standard proxy ARP and local proxy ARP, ARP Detection function (check based on DHCP Snooping security entries, 802.1x entries, or IP/MAC static binding entries), Flow mirroring, N: 4 port mirroring, Local and remote port mirroring, MCE, LDP protocol, MPLS TE, MPLS OAM, P/PE Functional Requirements of MPLS VPN, QoS / ACL 802.1P/DSCP priority remarking |
| Diğer Özellikler 7: | CAR traffic limit, Traffic policing and traffic shaping, Queue scheduling methods such as SP, WRR, SP+WRR, etc., Congestion avoidance mechanisms such as Tail-Drop and WRED, Traffic classification based on each field of the L2/L3/L4 protocol header, Ingress and Egress ACL, match L2/L3/L4 and IP quintuple, copy, forward and discard, Hash origin and same destination load balancing to ensure session integrity of traffic output |
| Diğer Özellikler 8: | Optional power supply 1+1 backup, HSRP, VRRP hot standby protocol, ISSU (In-Service Software Upgrade), EAPS, ERPS ring network protection, GR for OSPF, BGP, BFD for OSPF, BGP, Static/ LACP link aggregation, cross-service card link aggregation, IEEE802.3az green energy Ethernet |
| Diğer Özellikler 9: | CCC, CE mark, commercial, CE/LVD EN62368-1, FCC Part 15 Class B, RoHS |
