Ürün Kodu: RS-ES-300-28GPX
| Bağlantı Noktası Sayısı: | 28 |
| Sabit Bağlantı Noktaları Açıklaması: | 4 adet 1G/10G SFP+ fiber port yuvası 24 adet 10/100/1000Base-T PoE destekli bakır port |
| Anahtar Bant Genişliği: | 128 Gbps |
| Yığınlama: | Yığınlama desteği yoktur |
| Yönetim Yazılımı: | WEB GUI, CLI Konsol, SNMP, SSH, SSL |
| Paket İletim Hızı (Mpps): | 95.23 Mpps |
| Güvenlik 1: | 802.1X Dynamic VLAN and Guest VLAN, SSL guarantees data transmission security, Quad binding function of IP+MAC+VLAN+ports, MAC address learning limit, MAC address black hole, Anti DoS attack, Port broadcast message suppression, Port based and MAC Based IEEE802.1X authentication |
| Güvenlik 2: | SSH 2.0 provides a secure encrypted channel for user login, Host data backup mechanism, ARP intrusion detection function, Port isolation, IP Source Guard, ARP message speed limit function, IP Source Guard function, AAA&RADIUS and TACACS+ certification, Port Security, Hierarchical user management and password protection |
| Fiziksel Özellikler: | Calısma sıcaklıgı -20°C / +55°C aralıgına sahip IP30 19-inch Rack Montaj, 16K MAC Adresi, 600watt PoE bütçesi,440*290*44.5mm, <5.3kg |
| Diğer Özellikler 1: | IEEE802.3x flow control (Full duplex), Port exception protection mechanism, Port real-time flow management (Flow Interval), Broadcast storm suppression based on port rate, Optical port SFP module DDMI real-time digital diagnosis, Limit the rate of incoming and outgoing packet traffic, with min granularity of 16Kbps and max of 1Gbps, Port EEE Green Ethernet Energy-Saving configuration and status view, Jumbo frame configuration, the largest 12000byte |
| Diğer Özellikler 2: | Support dual-stack management, Support L2+ network management, ARP protocol, 1024 entries at most, RIPv1/v2, RIPng , OSPFv1/v2, OSPFv3, Support IPv4/ IPv6 static routing, each supporting 128 entries |
| Diğer Özellikler 3: | VLAN based on MAC, VLAN based on the protocol, Port configuration of Access, Trunk, Hybrid. GVRP VLAN protocol, (4K) VLAN ID,1K VLAN based on port, IEEE802.1q, Voice VLAN, QinQ configuration |
| Diğer Özellikler 4: | 802.3ad LACP dynamic aggregation, Static aggregation, 8 ports per group, 14 grup per device,STP BPDU Guard, BPDU filtering and BPDU forwarding, STP (IEEE802.1d), RSTP (IEEE802.1w), MSTP (IEEE802.1s), Support ERPS ring network, ring network self-healing time is less than 20ms, |
| Diğer Özellikler 5: | ITU-T G.8032, MLD Snooping, IGMP Snooping, Multicast VLAN, User quick log out, MVR (Multicast VLAN registration), IGMP Snooping v1/v2/v3 and 1024 multicast groups at most, Bidirectional traffic mirroring for basic ports, Supports 1-to-multiple mirroring, supports up to 4 port sessions |
| Diğer Özellikler 6: | Queue Scheduling Algorithm (SP, WRR, SP+WRR), Flow-based Rate Limiting, Stream based redirection, Flow-based Packet Filtering, 8*Output queues of each port, 802.1p/ DSCP priority mapping, Diff-Serv QoS, Priority Mark/ Remark, L2-L3-L4 Priority, ACL distribution based on port and VLAN, |
| Diğer Özellikler 7: | L2-L4 packet filtering function, matching the first 80 bytes message, and provides ACL definitions based on source MAC address, destination MAC address, source IP address, destination IP address, IP protocol type, TCP/UDP port, TCP/UDP port range, VLAN, etc. |
| Diğer Özellikler 8: | Link Layer Discovery Protocol (LLDP), Viewing CPU instant utilization status, Web network management (https), syslog, Console/ AUX Modem/ Telnet/ CLI configuration, Cable status check, Ping detection, System work log, NTP clock, One click restore, SNMP V1/V2/V3, RMON4, Rubisec NMS platform cluster management (LLDP+SNMP), FTP, TFTP, Xmodem, SFTP file upload and download management, Multiple Configuration File |
| Diğer Özellikler 9: | CCC, CE mark, commercial, CE/LVD EN62368-1, FCC Part 15 Class B, RoHS |
