Ürün Kodu: AXIS M4215-LV - 02677-001
Varifocal 2 MP dome with IR and deep learning Great image quality in 2 MP Varifocal lens with remote zoom and focus Lightfinder, WDR, and OptimizedIR Analytics with deep learning HDMI output for public viewing monitors
| Tip: | DOME |
| Ortam Tipi: | İÇ ORTAM |
| Sinyal Tipi: | NETWORK IP |
| Montaj Tipi: | TAVAN/DUVAR |
| Çözünürlük: | 1920 x 1080 |
| Sensör Tipi: | 1/2.8” progressive scan RGB CMOS |
| Lens Tipi: | Varifocal |
| Lens Boyutu (mm): | 3.5–6.6 mm, F1.7 - 2.6 |
| İnfrared Mesafesi (m): | OptimizedIR with power-efficient, long-life 850nm IR LEDs Range of reach 20m (65ft) or more depending on the scene |
| Optik Zoom Oranı (X): | 0 |
| Dijital Zoom Oranı (X): | Digital PTZ |
| S/N Oranı (dB): | 0 |
| Koruma Tipi: | IP42 ingress protection, IK08 impact-resistant, polycarbonate , and aluminum casing with hard-coated dome Encapsulated electronics , Color: white NCS S 1002-B |
| Koruma Standartları: | IP42 / IK08 |
| Besleme Tipi: | Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3 |
| Güç Tüketimi (W): | Typical 4.8 W, max 9.5 W |
| Protokoller: | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, TLS, QoS Layer , 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCP, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Link-Localaddress (ZeroConf) |
| Sıkıştırma Tipi: | H.264 (MPEG-4 Part 10/AVC) Main and High Profiles , H.265 (MPEG-H Part 2/HEVC) Main Profile Motion JPEG |
| Ağ Arabirimi: | RJ45 10BASE-T/100BASE-TX PoE HDMI type D , Audio: Audio and I/O connectivity via portcast technology |
| SD Kart: | Support for microSD/microSDHC/microSDXC card Recording to network-attached storage (NAS) |
| Otomatik Kazanç Kontrolü: | EVET/VAR |
| Otomatik Beyaz Dengesi: | EVET/VAR |
| Arka Aydınlatma Kompanzasyonu: | EVET/VAR |
| Arka Işık Maskeleme: | EVET/VAR |
| Gündüz/Gece: | EVET/VAR |
| Dijital Gürültü Azaltma: | EVET/VAR |
| Akıllı İnfrared: | EVET/VAR |
| Koyulaştırıcı: | EVET/VAR |
| Yansıtma: | EVET/VAR |
| Hareket Algılama: | EVET/VAR |
| Yüz Algılama: | HAYIR/YOK |
| On Screen Ekran Menüsü: | HAYIR/YOK |
| Gizlilik Maskeleme: | EVET/VAR |
| Gizlilik Bölgesi: | EVET/VAR |
| Wide Dynamic Range: | EVET/VAR |
| Analog Video Çıkışı: | HAYIR/YOK |
| Alarm Giriş: | HAYIR/YOK |
| Alarm Çıkış: | HAYIR/YOK |
| Mikrofon Girişi: | HAYIR/YOK |
| ONVIF: | ONVIF® Profile G, M, S and T |
| Isıtıcı: | HAYIR/YOK |
| Fan: | HAYIR/YOK |
| Muhafaza: | HAYIR/YOK |
| Ayak: | HAYIR/YOK |
| Gelişmiş Fonksiyonlar: | Deep learning processing unit (DLPU) , AXIS Object Analytics , Object classes: humans, vehicles(types: cars, buses, trucks, bikes) , Scenarios: line crossing, object in area, occupancy in area, time in area Up to10 scenarios Metadata visualized with color-coded bounding boxes Polygon include/exclude-areas Perspective configuration ONVIF Motion Alarm event Metadata , Object data: Classes: humans, faces, vehicles(types: cars, buses, trucks, bikes), license plates , Attributes: Vehicle color, upper/lower clothing color, confidence, position Eventdata: Producer reference, scenarios, trigger conditions Applications , Included: AXIS Object Analytics, AXIS Video Motion Detection, AXIS Face Detector, AXIS Live Privacy Shield, active tampering alarm Supported:AXIS People Counter AXIS Queue Monitor AXIS Camera Application Platform enabling installation of third-party applications ,seeaxis.com/acap |
| Diğer Özellikler 1: | Cybersecurity Edge security , Software: Signed firmware, brute force delay protection, digest authentication, and OAuth 2.0 RFC6749 OpenID Authorization Code Flow for centralized ADFS account management, password protection, AES-XTS-Plain64 256bit SD card encryption Hardware: Axis Edge Vault cybersecurity platform Secure element (CC EAL 6+), system-on-chip security (TEE), Axis device ID, secure keystore, signed video, secure boot, encrypted filesystem (AES-XTS-Plain64 256bit) |
| Diğer Özellikler 2: | Network security IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AR, HTTPS/HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509 Certificate PKI, IP address filtering |
| Diğer Özellikler 3: | Documentation , AXIS OS Hardening Guide Axis Vulnerability Management Policy Axis Security Development Model , AXIS OS Software Bill of Material (SBOM) To download documents, go to axis.com/support/cybersecurity/resources , To read more about Axis cybersecurity support, go to axis.com/cybersecurity |
This discreet dome delivers great images in any light conditions. With a deep learning processing unit, it offers intelligent analytics based on deep learning on the edge. Plus, Axis Edge Vault safeguards your device.
Ideal for indoor surveillance applications, AXIS M4215-LV delivers great image quality in 2 MP. With a varifocal lens, this affordable camera offers a flexible field of view. Plus, with remote zoom and auto focus capabilities, it ensures sharp high resolution video with great details where needed. Thanks to Lightfinder and WDR, it provides details even in challenging light conditions. And Axis OptimizedIR allows for surveillance in pitch darkness. Furthermore, Axis Edge Vault provides a hardware-based cybersecurity platform that guarantees the device’s integrity and protects it from unauthorized access.
AXIS M4215-LV offers great possibilities to add value to your camera and extend the functionality of your surveillance system. For instance, with an HDMI port and AXIS Face Detector you can display live video and face detection on a public viewing monitor to help deter theft. Plus, you can add audio or I/O connectivity using AXIS T61 Series. It offers advanced analytics based on deep learning on the edge to deliver valuable metadata facilitating efficient forensic search capabilities in live or recorded video. And AXIS Object Analytics including time in area feature lets you track whenever an object stays in a defined area longer than a user-defined time, for example, to detect loitering.
Compact and flexible in design, this varifocal dome offers flexible and discreet installation. With a wide range of accessories, it can be installed almost anywhere making it ideal for any location where discreet monitoring is needed. And it can be easily repainted to blend in seamlessly with any environment. This IK08-rated camera is protected against redirection, defocusing, and impact. A smoked dome is available as an accessory to disguise which way the camera is pointing. Furthermore, thanks to its vandal-, impact-, and dust-resistant casing you can be confident it’s always safe and secure.
